EcoFlow DELTA Pro Portable Power Station, 3600Wh

User Manual

Introducing the world's first portable home battery with an expandable ecosystem for home backup, smart energy management, lower energy bills, and more. The EcoFlow DELTA Pro is the next leap in portable power technology, offering you power security and independence, wherever you are.

The Portable Home Battery – EcoFlow DELTA Pro sports a 3.6kWh capacity that can be expanded all the way to 25kWh. You can integrate it directly with your home circuits via the EcoFlow Smart Home Panel. Ideal for home backup.

Power Pretty Much Anything – EcoFlow DELTA Pro leads the industry when it comes to AC output. The 3600W output, which can be increased up to 4500W with X-Boost, can power heavy-duty appliances such as dryers, AC units and more.

An Expandable Ecosystem – EcoFlow DELTA Pro is more than a portable power station. It can be expanded with extra batteries, EcoFlow Smart Generators and even the EcoFlow Smart Home Panel. Controlled all via an EcoFlow DELTA Pro Remote Control or your phone with the EcoFlow app.

Fully Charge in 1.9 Hours - EcoFlow’s X-Stream charging technology isn't just fast, it's safe too. The battery management system ensures safety and longevity while you fully charge DELTA Pro from a standard AC wall outlet in 1.9 hours.

Solar Powered Potential - EcoFlow's suite of solar products give you a cost-effective renewable energy source to stay powered. You can use solar energy to charge the DELTA Pro. The EcoFlow DELTA Pro has a wide voltage range from 11-150V, which makes it compatible with 90% of third-party solar panels with MC4 connectors.

Long Lasting Battery - DELTA Pro sports a brand-new LFP battery with 6500 cycles, which means you can use the DELTA Pro for years and years. The EcoFlow’s battery management system provides real-time analysis and regulation of voltage, current, and temperature. This unique protection mechanism makes DELTA Pro an incredibly safe and efficient home battery.

Multiple Ways to Control & Monitor. - Control the DELTA Pro either on the unit itself or unlock a ton of customization via the EcoFlow app. On the app, you can access your power settings, such as charging and discharging levels, AC charge speeds and a whole lot more.

Features:

• Expandable capacity and ecosystem
• Power Pretty Much Anything (3600W-4500W Output)
• Fully charge from AC in 1.9 hours
• Solar power capabilities
• Long lasting battery with 6500 charge cycles
• EcoFlow app for greater control and customization

Specifications:

• Capacity: 3600Wh
• Cycle Life: 6,500 cycles to 50% capacity, 3,500 cycles to 80% capacity
• AC Charge Input: 2900W Max
• AC Charge Input (Voltage and Amperage): 230V~12.5A
• AC Output: 4 outlets, 230V/16A, 3600W (Surge 7200W)
• USB-A Output (x2): 5V, 2.4A, 12W Max per port
• USB-C Output (x2): 5/9/12/15/20V, 5A, 100W Max per port
• DC5521 Output (x2): 6V, 3A, 38W Max per port
• Car Charge Input: Support 12V/24V battery, 8A
• Max Device(s) Power Supported by X-Boost: 4500W
• USB-A Fast Charge (x2): 5V, 2.4A / 9V, 2A / 12V, 1.5A, 18W Max per port
• Car Charger Output (x1): 6V, 10A, 126W Max
• Anderson Port: 6V, 30A
• Solar Charging Input: 1600W Max, 11-150V, 15A
• Connection: Wi-Fi, Bluetooth, wired

Includes:

• DELTA Pro
• AC Charging Cable
• Car Charging Cable
• DC5521 to DC5525 cable
• Handle Cover
• User Manual
